Part W11831578 Electronic Control Board
Purpose
Coordinates all washer functions including timing, sensors, and motor operation.
Details
The W11831578 is a genuine OEM electronic control board (CCU) for Whirlpool-manufactured top-load washing machines. As the primary "brain" of the appliance, this board manages electrical signals for the water inlet valve, drain pump, motor, and lid lock. It processes data from the pressure transducer and other internal sensors to automate wash cycles according to user selections. Common symptoms of a failing control board include the washer failing to start, the drain pump running continuously even when the unit is off, intermittent cycle interruptions, or the display of specific error codes related to communication or sensor faults. This updated module replaces several previous versions to improve overall system reliability and timing accuracy.
Included Items
One (1) Electronic Control Board Assembly; Required tools: 1/4" nut driver or Phillips-head screwdriver, and a putty knife (to release console clips).
Compatible Brands
Whirlpool, Maytag, Kenmore, Amana, Roper, Inglis
Replaces
W11777413, W11712987, W11368855, W11298479, W11689483, AP8089626
Highlights
- Genuine OEM part
- Application: Top-Load Laundry Control System
- Purpose: Main logic and power distribution management
- Features: Integrated pressure sensor for water level detection
- Installation difficulty: Moderate
Safety Note
Always disconnect power and water supply before servicing. Follow model-specific diagrams and safety instructions for installation. Discharge static electricity before handling the board to prevent sensitive component damage.
